Spectrum Specifications |
|
|---|---|
|
GSM Frequency (Eurasian Version) |
GSM: 850/900/1800/1900MHz WCDMA: B1/B2/B5/B8 FDD LTE: B1/B3/B5/B7/B8/B19/B20 TDD LTE: B38/B39/B40/B41 (100M) |
|
GSM Frequency (American Version) |
GSM: 850/1800/1900MHz WCDMA: B2/B4/B5 FDD LTE: B2/B3/B4/B5/B7/B12/B17 TDD LTE: B38/B41 (100M) |
| WiFi | 2.4GHz, 802.11 b/g/n |
| BT | BLE 4.0 |
| Memory | SD Card (Max 256 GB) |
| Speaker & Mic | Yes |
| SIM Card | Micro or Nano |
GNSS Specifications |
|
|---|---|
| CPU | Quad-core 1.4GHz A53 |
| Operating System | Android 8.1 GO |
| GNSS | GPS+BDS |
| G-Sensor | 6-oxls |
| GPS chipset | High sensitivity GPS chips |
| Location accuracy | <10 meters |
| Tracking sensitivity | -165dBm |
| Acquisition sensitivity | -148dBm |
| TTFF (open sky) | Avg. hot start≤1sec, Avg. cold start≤40sec |
| Data Interface | Micro USB 2.0 |
| LED | Red (Power), Blue (Cellular), Green (GNSS) |
| Camera - Main Unit | Front camera: 1920x 1080/25FPS/F2.2/full color |
| Camera - Subcamera | DMS camera: 1280x720/10FPS/F2.0/monochrome all day |
| Camera - Image Format | H.264 |
Other Specifications | |
|---|---|
| Battery | External: 450mAh |
| Power Supply | Power coble: B+/ACC/GND |
| Operating Temperature | -20°C to +65°C |
| Working Voltage/current | 9-30V DC |
| Device Dimension | 109.0 x 69.0 x 52.0 mm ( L x W x H ) |
| Weight | 233g |
| Certifications | FCC/CE/RoHS |
