Spectrum Specifications |
|
|---|---|
| Communication Network | 4G LTE |
| WiFi | 2.4GHz |
| Band |
AVC450-A (for North American Countries and Regions) FDD-LTE: B2/B4/B5/B12/B13/B14/B66 WCDMA: B2/B4/B5 |
|
AVC450-E (for European and Asian Countries and Regions) FDD-LTE: B1/B3/B7/B8/B20/B28A TDD-LTE: B38/B40 WCDMA: B1/B8 GSM: B3/B8 |
|
|
AVC450-LA (for Latin American Countries and Regions) FDD-LTE: B1/B2/B3/B4/B5/B7/B8/B28 TDD-LTE: B40 WCDMA:B1/B2/B4/B5/B8 GSM: B2/B3/B5/B8 |
|
| Sim | Nano SIM |
| Bluetooth | BT 4.0 |
| Expandable Memory | Dual-Micro SD supported (max. 256GB for each) |
| GNSS | GPS and BDS |
GNSS Specifications |
|
|---|---|
| Power consumption | DC 9-33V (Suitable for 12V and 24V vehicles) |
| Extension Interface(optional) | 1*Relay, 2*RS232, 2*Input, 1*AV-out |
Other Specifications | |
|---|---|
| Environment Requirement | Operating temperature: -20℃to 70℃ Storage temperature: -30℃to 85℃ |
| Storage | MicroSD/TF Card (Up to 256GB) |
| Speaker & Microphone | Built-In |
| Camera | Main Unit - Front camera: 1280x720/15FPS/F2.0/Full Colour /85° (HFoV), Subcamera: 1280x720/15FPS/F2.5/Full Colour in daytime & monochrome in dim light/90° (HFoV) |
| Video Format | .ts |
